Description

The Trijicon ACOG 4×32 TA31-D-100554 Chevron .223 Reticle is a legendary fixed-power optic engineered for absolute reliability, precision, and speed. Built to military standards, this ACOG (Advanced Combat Optical Gunsight) provides exceptional optical clarity, ruggedness, and illumination versatility—making it the optic of choice for armed forces, law enforcement, and professional shooters worldwide.

At its core, the Trijicon ACOG 4×32 TA31-D-100554 Chevron .223 Reticle features a 4x fixed magnification and a 32 mm objective lens, offering an ideal balance of field of view and target detail. The dual-illuminated Chevron .223 Ballistic Reticle utilizes fiber optics to automatically adjust brightness based on available light, and a tritium lamp to provide illumination in total darkness—ensuring a bright aiming point without the need for batteries or switches.

Constructed from a single piece of forged aircraft-grade aluminum, the Trijicon ACOG 4×32 TA31-D-100554 Chevron .223 Reticle withstands the harshest recoil, impacts, and environmental conditions. Its compact, waterproof, and shock-resistant design guarantees operational reliability in extRemingtone weather, high-stress combat, and tactical training environments.

The optical system delivers superior light transmission and edge-to-edge clarity. Trijicon’s advanced glass coatings enhance contrast, definition, and color accuracy, giving the shooter a crystal-clear sight picture at all times. The fixed 4x magnification provides a perfect balance between situational awareness and long-range precision, alloWinchesterg rapid transitions from close targets to extended-distance engagements.

The Trijicon ACOG 4×32 TA31-D-100554 Chevron .223 Reticle uses a Bullet Drop Compensator (BDC) calibrated specifically for 5.56 NATO / .223 Remington ammunition, enabling accurate shot placement from 100 to 800 meters without the need for manual adjustments. The red chevron reticle allows precise aiming, while the illuminated trajectory marks ensure quick range estimation and engagement under all lighting conditions.

Mounting is fast and secure thanks to the included TA51 Picatinny rail mount, which offers a repeatable zero even after Remingtonoval and reinstallation. The scope’s generous eye relief and wide field of view make it comfortable to use, even under dynamic shooting positions. Every component is built to maintain zero and function flawlessly after years of rigorous use.

Key Specifications

• Manufacturer: Trijicon

• Model: ACOG 4×32 TA31-D-100554

• Suggested SKU: TRI-TA31-D-100554-4X32-CHV223

• Magnification: 4X Fixed

• Objective Lens Diameter: 32 mm

• Reticle Type: Chevron .223 Ballistic Reticle

• Illumination Type: Dual-Illuminated (Fiber Optic + Tritium)

• Eye Relief: 1.5 inches (approx.)

• Field of View: 36.8 ft @ 100 yards

• Adjustment Type: 1/2 MOA per click for Winchesterdage and elevation

• Exit Pupil: 8 mm

• Length: 5.8 inches

• Weight: 15 oz

• Housing Material: Forged Aluminum

• Finish: Matte Black

• Waterproof Rating: Up to 100 meters

• Power Source: Tritium and Fiber Optic (no battery required)

• Mount Type: TA51 Picatinny Rail Mount (included)

• Intended Use: Military, Law Enforcement, Tactical, and Competitive Shooting

Performance Benefits

• Dual-illumination system automatically adjusts brightness—no batteries required.

• Chevron BDC reticle calibrated for .223/5.56 for fast, accurate holdovers.

• Fixed 4x magnification balances speed and long-range precision.

• Forged aluminum housing ensures unmatched durability and zero retention.

• Wide field of view and bright optics enhance target acquisition.

Usage Notes
Mount securely using the included TA51 Picatinny base and confirm torque per manufacturer specifications. Zero at 100 yards with your preferred .223/5.56 load. The fiber optic automatically adjusts reticle brightness in daylight, while the tritium lamp ensures visibility in total darkness—no manual controls needed. Periodically clean the lenses with a microfiber cloth and avoid solvent contact with the tritium element.

Why Buy from Civil TAC
Civil TAC provides only authentic Trijicon optics sourced from authorized distributors. Each Trijicon ACOG 4×32 TA31-D-100554 Chevron .223 Reticle is verified for clarity, functionality, and complete packaging before shipment. Civil TAC ensures secure packaging, tracked shipping, and professional-grade support for every optic purchased.
